Linux内核硬中断 / 软中断的原理和实现

/** * irq: 要分配的中断号 * handler: 要注册的中断处理函数 * flags: 标志(一般为0) * name: 设备名(dev->name) * dev: 设备(struct net_device *dev)，作为中断处理函数的参数 * 成功返回0 */int request_irq(unsigned int irq, irq_handler_t handler, unsigned long flags,     const char *name, void *dev);

typedef irqreturn_t (*irq_handler_t) (int, void *);/** * enum irqreturn * @IRQ_NONE: interrupt was not from this device * @IRQ_HANDLED: interrupt was handled by this device * @IRQ_WAKE_THREAD: handler requests to wake the handler thread */enum irqreturn {    IRQ_NONE,    IRQ_HANDLED,    IRQ_WAKE_THREAD,};typedef enum irqreturn irqreturn_t;#define IRQ_RETVAL(x) ((x) != IRQ_NONE)

/** * free_irq - free an interrupt allocated with request_irq * @irq: Interrupt line to free * @dev_id: Device identity to free * * Remove an interrupt handler. The handler is removed and if the * interrupt line is no longer in use by any driver it is disabled. * On a shared IRQ the caller must ensure the interrupt is disabled * on the card it drives before calling this function. The function does * not return until any executing interrupts for this IRQ have completed. * This function must not be called from interrupt context. */void free_irq(unsigned int irq, void *dev_id);

struct softirq_action {    void (*action) (struct softirq_action *); /* 软中断的处理函数 */};

static struct softirq_action softirq_vec[NR_SOFTIRQS];enum {    HI_SOFTIRQ = 0, /* 优先级高的tasklets */    TIMER_SOFTIRQ, /* 定时器的下半部 */    NET_TX_SOFTIRQ, /* 发送网络数据包 */    NET_RX_SOFTIRQ, /* 接收网络数据包 */    BLOCK_SOFTIRQ, /* BLOCK装置 */    BLOCK_IOPOLL_SOFTIRQ,    TASKLET_SOFTIRQ, /* 正常优先级的tasklets */    SCHED_SOFTIRQ, /* 调度程序 */    HRTIMER_SOFTIRQ, /* 高分辨率定时器 */    RCU_SOFTIRQ, /* RCU锁定 */    NR_SOFTIRQS /* 10 */};

/** * @nr: 软中断的索引号 * @action: 软中断的处理函数 */void open_softirq(int nr, void (*action) (struct softirq_action *)){    softirq_vec[nr].action = action;}

void raise_softirq(unsigned int nr){    unsigned long flags;    local_irq_save(flags);    raise_softirq_irqoff(nr);    local_irq_restore(flags);}/* This function must run with irqs disabled */inline void rasie_softirq_irqsoff(unsigned int nr){    __raise_softirq_irqoff(nr);    /* If we're in an interrupt or softirq, we're done     * (this also catches softirq-disabled code). We will     * actually run the softirq once we return from the irq     * or softirq.     * Otherwise we wake up ksoftirqd to make sure we     * schedule the softirq soon.     */    if (! in_interrupt()) /* 如果不处于硬中断或软中断 */        wakeup_softirqd(void); /* 唤醒ksoftirqd/n进程 */}

static inline void __rasie_softirq_irqoff(unsigned int nr){    trace_softirq_raise(nr);    or_softirq_pending(1UL << nr);}typedef struct {    unsigned int __softirq_pending;    unsigned int __nmi_count; /* arch dependent */} irq_cpustat_t;irq_cpustat_t irq_stat[];#define __IRQ_STAT(cpu, member) (irq_stat[cpu].member)#define or_softirq_pending(x) percpu_or(irq_stat.__softirq_pending, (x))#define local_softirq_pending() percpu_read(irq_stat.__softirq_pending)

static void wakeup_softirqd(void){    /* Interrupts are disabled: no need to stop preemption */    struct task_struct *tsk = __get_cpu_var(ksoftirqd);    if (tsk && tsk->state != TASK_RUNNING)        wake_up_process(tsk);}

asmlinkage void do_softirq(void){    __u32 pending;    unsigned long flags;    /* 如果当前已处于硬中断或软中断中，直接返回 */    if (in_interrupt())         return;    local_irq_save(flags);    pending = local_softirq_pending();    if (pending) /* 如果有激活的软中断 */        __do_softirq(); /* 处理函数 */    local_irq_restore(flags);}

/* We restart softirq processing MAX_SOFTIRQ_RESTART times, * and we fall back to softirqd after that. * This number has been established via experimentation. * The two things to balance is latency against fairness - we want * to handle softirqs as soon as possible, but they should not be * able to lock up the box. */asmlinkage void __do_softirq(void){    struct softirq_action *h;    __u32 pending;    /* 本函数能重复触发执行的次数，防止占用过多的cpu时间 */    int max_restart = MAX_SOFTIRQ_RESTART;    int cpu;    pending = local_softirq_pending(); /* 激活的软中断位图 */    account_system_vtime(current);    /* 本地禁止当前的软中断 */    __local_bh_disable((unsigned long)__builtin_return_address(0), SOFTIRQ_OFFSET);    lockdep_softirq_enter(); /* current->softirq_context++ */    cpu = smp_processor_id(); /* 当前cpu编号 */restart:    /* Reset the pending bitmask before enabling irqs */    set_softirq_pending(0); /* 重置位图 */    local_irq_enable();    h = softirq_vec;    do {        if (pending & 1) {            unsigned int vec_nr = h - softirq_vec; /* 软中断索引 */            int prev_count = preempt_count();            kstat_incr_softirqs_this_cpu(vec_nr);            trace_softirq_entry(vec_nr);            h->action(h); /* 调用软中断的处理函数 */            trace_softirq_exit(vec_nr);            if (unlikely(prev_count != preempt_count())) {                printk(KERN_ERR "huh, entered softirq %u %s %p" "with preempt_count %08x,"                    "exited with %08x?\n", vec_nr, softirq_to_name[vec_nr], h->action, prev_count,                    preempt_count());            }            rcu_bh_qs(cpu);        }        h++;        pending >>= 1;    } while(pending);    local_irq_disable();    pending = local_softirq_pending();    if (pending & --max_restart) /* 重复触发 */        goto restart;    /* 如果重复触发了10次了，接下来唤醒ksoftirqd/n内核线程来处理 */    if (pending)        wakeup_softirqd();     lockdep_softirq_exit();    account_system_vtime(current);    __local_bh_enable(SOFTIRQ_OFFSET);}

static int run_ksoftirqd(void *__bind_cpu){    set_current_state(TASK_INTERRUPTIBLE);    current->flags |= PF_KSOFTIRQD; /* I am ksoftirqd */    while(! kthread_should_stop()) {        preempt_disable();        if (! local_softirq_pending()) { /* 如果没有要处理的软中断 */            preempt_enable_no_resched();            schedule();            preempt_disable():        }        __set_current_state(TASK_RUNNING);        while(local_softirq_pending()) {            /* Preempt disable stops cpu going offline.             * If already offline, we'll be on wrong CPU: don't process.             */             if (cpu_is_offline(long)__bind_cpu))/* 被要求释放cpu */                 goto wait_to_die;            do_softirq(); /* 软中断的统一处理函数 */            preempt_enable_no_resched();            cond_resched();            preempt_disable();            rcu_note_context_switch((long)__bind_cpu);        }        preempt_enable();        set_current_state(TASK_INTERRUPTIBLE);    }    __set_current_state(TASK_RUNNING);    return 0;wait_to_die:    preempt_enable();    /* Wait for kthread_stop */    set_current_state(TASK_INTERRUPTIBLE);    while(! kthread_should_stop()) {        schedule();        set_current_state(TASK_INTERRUPTIBLE);    }    __set_current_state(TASK_RUNNING);    return 0;}
