一、背景
为了安全，Linux 中分为用户态和内核态两种运行状态。对于普通进程，平时都是运行在用户态下，仅拥有基本的运行能力。当进行一些敏感操作，比如说要打开文件(open)然后进行写入(write)、分配内存(malloc)时，就会切换到内核态。内核态进行相应的检查，如果通过了，则按照进程的要求执行相应的操作，分配相应的资源。这种机制被称为系统调用，用户态进程发起调用，切换到内核态，内核态完成，返回用户态继续执行，是用户态唯一主动切换到内核态的合法手段(exception 和 interrupt 是被动切换)。
关于系统调用的详细定义可以通过 man syscalls 查看，它列出了目前 Linux Kernel 提供的系统调用 ABI 。我们熟悉的调用比如 open， read ，close 之类的都属于系统调用，但它们都经过了 C 库 (glibc)的封装。实际上，只要符合 ABI 规范，我们可以自己用汇编代码来进行调用。
历史上，x86 的系统调用实现经历了 int / iret 到 sysenter / sysexit 再到 syscall / sysret 的演变。
以下的分析基于 Linux kernel 4.9.76 ，glibc 为 2.25.90。
二、int / iret
很久很久以前，我们通过 int 0x80 进行系统调用(open)：
mov 0x05 ,eax /* 设置系统调用号 */int 0x80
在 arch/x86/kernel/traps.c 的 trap_init 中，定义了各种 set_intr_gate / set_intr_gate_ist / set_system_intr_gate 。其中 set_system_intr_gate 用于在中断描述符表(IDT)上设置系统调用门：
#ifdef CONFIG_X86_32set_system_intr_gate(IA32_SYSCALL_VECTOR, entry_INT80_32);set_bit(IA32_SYSCALL_VECTOR, used_vectors);#endif
根据 arch/x86/include/asm/irq_vectors.h， IA32_SYSCALL_VECTOR 值为 0x80。
于是在调用 int 0x80 后，硬件根据向量号在 IDT 中找到对应的表项，即中断描述符，进行特权级检查，发现 DPL = CPL = 3 ，允许调用。然后硬件将切换到内核栈 (tss.ss0 : tss.esp0)。接着根据中断描述符的 segment selector 在 GDT / LDT 中找到对应的段描述符，从段描述符拿到段的基址，加载到 cs 。将 offset 加载到 eip。最后硬件将 ss / sp / eflags / cs / ip / error code 依次压到内核栈。
于是从 entry_INT80_32 开始执行，其定义在 arch/x86/entry/entry_32.S ：
ENTRY(entry_INT80_32)ASM_CLACpushl %eax /* pt_regs->orig_ax */SAVE_ALL pt_regs_ax=$-ENOSYS /* save rest *//** User mode is traced as though IRQs are on, and the interrupt gate* turned them off.*/TRACE_IRQS_OFFmovl %esp, %eaxcall do_int80_syscall_32...
它将存在 eax 中的系统调用号压入栈中，然后调用 SAVE_ALL 将其他寄存器的值压入栈中进行保存：
.macro SAVE_ALL pt_regs_ax=%eaxcldPUSH_GSpushl %fspushl %espushl %dspushl \pt_regs_axpushl %ebppushl %edipushl %esipushl %edxpushl %ecxpushl %ebxmovl $(__USER_DS), %edxmovl %edx, %dsmovl %edx, %esmovl $(__KERNEL_PERCPU), %edxmovl %edx, %fsSET_KERNEL_GS %edx.endm
保存完毕后，关闭中断，将当前栈指针保存到 eax ，调用 do_int80_syscall_32 => do_syscall_32_irqs_on ，该函数在 arch/x86/entry/common.c 中定义：
static __always_inline void do_syscall_32_irqs_on(struct pt_regs *regs){struct thread_info *ti = current_thread_info();unsigned int nr = (unsigned int)regs->orig_ax;#ifdef CONFIG_IA32_EMULATIONcurrent->thread.status |= TS_COMPAT;#endifif (READ_ONCE(ti->flags) & _TIF_WORK_SYSCALL_ENTRY) {/** Subtlety here: if ptrace pokes something larger than* 2^32-1 into orig_ax, this truncates it. This may or* may not be necessary, but it matches the old asm* behavior.*/nr = syscall_trace_enter(regs);}if (likely(nr < IA32_NR_syscalls)) {/** It's possible that a 32-bit syscall implementation* takes a 64-bit parameter but nonetheless assumes that* the high bits are zero. Make sure we zero-extend all* of the args.*/regs->ax = ia32_sys_call_table[nr]((unsigned int)regs->bx, (unsigned int)regs->cx,(unsigned int)regs->dx, (unsigned int)regs->si,(unsigned int)regs->di, (unsigned int)regs->bp);}syscall_return_slowpath(regs);}
这个函数的参数 regs(struct pt_regs 定义见 arch/x86/include/asm/ptrace.h )就是先前在 entry_INT80_32 依次被压入栈的寄存器值。这里先取出系统调用号，从系统调用表(ia32_sys_call_table) 中取出对应的处理函数，然后通过先前寄存器中的参数调用之。
系统调用表 ia32_sys_call_table 在 arch/x86/entry/syscall_32.c 中定义，但内容有点奇怪，看上去表的内容是 include 进来的：
/* System call table for i386. */#include <linux/linkage.h>#include <linux/sys.h>#include <linux/cache.h>#include <asm/asm-offsets.h>#include <asm/syscall.h>#define __SYSCALL_I386(nr, sym, qual) extern asmlinkage long sym(unsigned long, unsigned long, unsigned long, unsigned long, unsigned long, unsigned long) ;#include <asm/syscalls_32.h>#undef __SYSCALL_I386#define __SYSCALL_I386(nr, sym, qual) [nr] = sym,extern asmlinkage long sys_ni_syscall(unsigned long, unsigned long, unsigned long, unsigned long, unsigned long, unsigned long);__visible const sys_call_ptr_t ia32_sys_call_table[__NR_syscall_compat_max+1] = {/** Smells like a compiler bug -- it doesn't work* when the & below is removed.*/[0 ... __NR_syscall_compat_max] = &sys_ni_syscall,#include <asm/syscalls_32.h>};
然而我们到源码的 arch/x86/include/asm 目录下却找不到 syscalls_32.h 的，但在编译 kernel 后的 arch/x86/include/generated/asm 里面发现了它：
__SYSCALL_I386(0, sys_restart_syscall, )__SYSCALL_I386(1, sys_exit, )#ifdef CONFIG_X86_32__SYSCALL_I386(2, sys_fork, )#else__SYSCALL_I386(2, sys_fork, )#endif__SYSCALL_I386(3, sys_read, )__SYSCALL_I386(4, sys_write, )#ifdef CONFIG_X86_32__SYSCALL_I386(5, sys_open, )#else__SYSCALL_I386(5, compat_sys_open, )...
这说明 syscalls_32.h 是在编译过程中动态生成的，请看脚本 arch/x86/entry/syscalls/syscalltbl.sh，它读取了同目录下的 syscall_32.tbl ，为每一有效行都生成了 __SYSCALL_${abi}($nr, $real_entry, $qualifier) 结构。然后在宏 __SYSCALL_I386 的作用下形成了这样的定义：
__visible const sys_call_ptr_t ia32_sys_call_table[__NR_syscall_compat_max+1] = {[0 ... __NR_syscall_compat_max] = &sys_ni_syscall,[0] = sys_restart_syscall,[1] = sys_exit,[2] = sys_fork,[3] = sys_read,[4] = sys_write,[5] = sys_open,...};
根据 GCC文档 ，这样的初始化方法在 ISO C99 中定义，个人称之为数组的乱序初始化。
因为我们的调用号是 0x05 ，所以这里调用了 sys_open ，定义在 fs/open.c 中定义：
SYSCALL_DEFINE3(open, const char __user *, filename, int, flags, umode_t, mode){if (force_o_largefile())flags |= O_LARGEFILE;return do_sys_open(AT_FDCWD, filename, flags, mode);}
宏 SYSCALL_DEFINE3 及相关定义如下：
#define SYSCALL_DEFINE3(name, ...) SYSCALL_DEFINEx(3, _##name, __VA_ARGS__)#define SYSCALL_DEFINEx(x, sname, ...) \SYSCALL_METADATA(sname, x, __VA_ARGS__) \__SYSCALL_DEFINEx(x, sname, __VA_ARGS__)#define __SYSCALL_DEFINEx(x, name, ...) \asmlinkage long sys##name(__MAP(x,__SC_DECL,__VA_ARGS__)) \__attribute__((alias(__stringify(SyS##name)))); \\static inline long SYSC##name(__MAP(x,__SC_DECL,__VA_ARGS__)); \\asmlinkage long SyS##name(__MAP(x,__SC_LONG,__VA_ARGS__)); \\asmlinkage long SyS##name(__MAP(x,__SC_LONG,__VA_ARGS__)) \{ \long ret = SYSC##name(__MAP(x,__SC_CAST,__VA_ARGS__)); \__MAP(x,__SC_TEST,__VA_ARGS__); \__PROTECT(x, ret,__MAP(x,__SC_ARGS,__VA_ARGS__)); \return ret; \} \\static inline long SYSC##name(__MAP(x,__SC_DECL,__VA_ARGS__))
SYSCALL_METADATA 保存了调用的基本信息，供调试程序跟踪使用( kernel 需开启 CONFIG_FTRACE_SYSCALLS )。
而 __SYSCALL_DEFINEx 用于拼接函数，函数名被拼接为 sys##_##open，参数也通过 __SC_DECL 拼接，最终得到展开后的定义：
asmlinkage long sys_open(const char __user * filename, int flags, umode_t mode){if (force_o_largefile())flags |= O_LARGEFILE;return do_sys_open(AT_FDCWD, filename, flags, mode);}
sys_open 是对 do_sys_open 的封装：
long do_sys_open(int dfd, const char __user *filename, int flags, umode_t mode){struct open_flags op;int fd = build_open_flags(flags, mode, &op);struct filename *tmp;if (fd)return fd;tmp = getname(filename);if (IS_ERR(tmp))return PTR_ERR(tmp);fd = get_unused_fd_flags(flags);if (fd >= 0) {struct file *f = do_filp_open(dfd, tmp, &op);if (IS_ERR(f)) {put_unused_fd(fd);fd = PTR_ERR(f);} else {fsnotify_open(f);fd_install(fd, f);}}putname(tmp);return fd;}
getname 将处于用户态的文件名拷到内核态，然后通过 get_unused_fd_flags 获取一个没用过的文件描述符，然后 do_filp_open 创建 struct file ， fd_install 将 fd 和 struct file 绑定(task_struct->files->fdt[fd] = file)，然后返回 fd。
fd一直返回到 do_syscall_32_irqs_on ，被设置到 regs->ax (eax) 中。接着返回 entry_INT80_32 继续执行，最后执行 INTERRUPT_RETURN 。INTERRUPT_RETURN 在 arch/x86/include/asm/irqflags.h 中定义为 iret ，负责恢复先前压栈的寄存器，返回用户态。系统调用执行完毕。
在目前主流的系统调用库(glibc) 中，int 0x80 只有在硬件不支持快速系统调用(sysenter / syscall)的时候才会调用，但目前的硬件都支持快速系统调用，所以为了能够看看 int 0x80 的效果，我们手撸汇编：
#include <stdio.h>#include <stdlib.h>#include <string.h>int main(){char * filename = "/tmp/test";char * buffer = malloc(80);memset(buffer, 0, 80);int count;__asm__ __volatile__("movl $0x5, %%eax\n\t""movl %1, %%ebx\n\t""movl $0, %%ecx\n\t""movl $0664, %%edx\n\t""int $0x80\n\t""movl %%eax, %%ebx\n\t""movl $0x3, %%eax\n\t""movl %2, %%ecx\n\t""movl $80, %%edx\n\t""int $0x80\n\t""movl %%eax, %0\n\t":"=m"(count):"g"(filename), "g"(buffer):"%eax", "%ebx", "%ecx", "%edx");printf("%d\n", count);printf("%s\n", buffer);free(buffer);}
这段代码首先通过 int 0x80 调用系统调用 open 得到 fd (由 eax 返回)，再作为 read 的参数传入，从而读出了文件中的内容。但比较奇怪的是如果 buffer 存储在栈中 (buffer[80])，则调用 read 失败。只有将 buffer 作为全局变量或存储在堆中，才能调用成功。希望有知道的大大指点一下。
三、sysenter / sysexit
接下来介绍的是 32位下 Intel 提出的快速系统调用 sysenter/sysexit，它和同期AMD的 syscall/sysret 机制类似。
之所以提出新指令，是因为通过软中断来实现系统调用实在太慢了。于是 Intel x86 CPU 自 Pentium II（Family 6, Model 3, Stepping 3）之后，开始支持新的系统调用指令 sysenter/sysexit。前者用于从低特权级切换到 ring 0，后者用于 从ring 0 切换到低特权级。没有特权级别检查(CPL, DPL)，也没有压栈的操作，快最重要！
在 Intel SDM 中阐述了sysenter指令。首先 CPU 有一堆特殊的寄存器，名为 Model-Specific Register(MSR)，这些寄存器在操作系统运行过程中起着重要作用。对于这些寄存器，需要采用专门的指令 RDMSR 和 WRMSR 进行读写。
sysenter 用到了以下 MSR (定义在 arch/x86/include/asm/msr-index.h)：
IA32_SYSENTER_CS(174H)：存放内核态处理代码的段选择符
IA32_SYSENTER_EIP(175H)：存放内核态栈顶偏移量
IA32_SYSENTER_ESP(176H)：存放内核态处理代码偏移量
当执行 sysenter 时，执行以下操作：
清除 FLAGS 的 VM 标志，确保在保护模式下运行
清除 FLAGS 的 IF 标志，屏蔽中断
加载 IA32_SYSENTER_ESP 的值到 esp
加载 IA32_SYSENTER_EIP 的值到 eip
加载 SYSENTER_CS_MSR 的值到 CS
将 SYSENTER_CS_MSR + 8 的值加载到 ss 。因为在GDT中， ss 就跟在 cs 后面
开始执行(cs:eip)指向的代码
这些 MSR 在 arch/x86/kernel/cpu/common.c 的 enable_sep_cpu 中初始化：
void enable_sep_cpu(void){struct tss_struct *tss;int cpu;if (!boot_cpu_has(X86_FEATURE_SEP))return;cpu = get_cpu();tss = &per_cpu(cpu_tss, cpu);/** We cache MSR_IA32_SYSENTER_CS's value in the TSS's ss1 field --* see the big comment in struct x86_hw_tss's definition.*/tss->x86_tss.ss1 = __KERNEL_CS;wrmsr(MSR_IA32_SYSENTER_CS, tss->x86_tss.ss1, 0);wrmsr(MSR_IA32_SYSENTER_ESP,(unsigned long)tss + offsetofend(struct tss_struct, SYSENTER_stack),0);wrmsr(MSR_IA32_SYSENTER_EIP, (unsigned long)entry_SYSENTER_32, 0);put_cpu();}
这里将 __KERNEL_CS 设置到 MSR_IA32_SYSENTER_CS 中，将 tss.SYSENTER_stack 地址设置到 MSR_IA32_SYSENTER_ESP 中，最后将内核入口点 entry_SYSENTER_32 的地址设置到 MSR_IA32_SYSENTER_EIP 中。
当用户程序进行系统调用时，实际上在用户态中最终会调用到 VDSO 中映射的 __kernel_vsyscall ，其定义位于 arch/x86/entry/vdso/vdso32/system_call.S：
__kernel_vsyscall:CFI_STARTPROCpushl %ecxCFI_ADJUST_CFA_OFFSET 4CFI_REL_OFFSET ecx, 0pushl %edxCFI_ADJUST_CFA_OFFSET 4CFI_REL_OFFSET edx, 0pushl %ebpCFI_ADJUST_CFA_OFFSET 4CFI_REL_OFFSET ebp, 0#define SYSENTER_SEQUENCE "movl %esp, %ebp; sysenter"#define SYSCALL_SEQUENCE "movl %ecx, %ebp; syscall"#ifdef CONFIG_X86_64/* If SYSENTER (Intel) or SYSCALL32 (AMD) is available, use it. */ALTERNATIVE_2 "", SYSENTER_SEQUENCE, X86_FEATURE_SYSENTER32, \SYSCALL_SEQUENCE, X86_FEATURE_SYSCALL32#elseALTERNATIVE "", SYSENTER_SEQUENCE, X86_FEATURE_SEP#endif/* Enter using int $0x80 */int $0x80GLOBAL(int80_landing_pad)/** Restore EDX and ECX in case they were clobbered. EBP is not* clobbered (the kernel restores it), but it's cleaner and* probably faster to pop it than to adjust ESP using addl.*/popl %ebpCFI_RESTORE ebpCFI_ADJUST_CFA_OFFSET -4popl %edxCFI_RESTORE edxCFI_ADJUST_CFA_OFFSET -4popl %ecxCFI_RESTORE ecxCFI_ADJUST_CFA_OFFSET -4retCFI_ENDPROC.size __kernel_vsyscall,.-__kernel_vsyscall.previous
__kernel_vsyscall 首先将寄存器当前值压栈保存，因为这些寄存器以后要用作系统调用传参。然后填入参数，调用 sysenter
ALTERNATIVE_2 宏实际上是在做选择，如果支持 X86_FEATURE_SYSENTER32(Intel CPU) ，则执行 SYSENTER_SEQUENCE ，如果支持 X86_FEATURE_SYSCALL32(AMD CPU)，则执行 SYSCALL_SEQUENCE 。如果都不支持，那么啥都不干(???)。如果啥都没干，那么接着往下执行，即执行 int $0x80，退化到传统(legacy)方式进行系统调用。
注意 sysenter 指令会覆盖掉 esp ，因此 SYSENTER_SEQUENCE 中会将当前 esp 保存到 ebp 中。sysenter 同样会覆盖 eip ，但由于返回地址是固定的(__kernel_vsyscall 函数结尾)，因此无需保存。
前文提到过，执行了 sysenter 指令之后直接切换到内核态，同时寄存器也都设置好了：eip 被设置为 IA32_SYSENTER_EIP 即 entry_SYSENTER_32 的地址，其定义在arch/x86/entry/entry_32.S中：
ENTRY(entry_SYSENTER_32)movl TSS_sysenter_sp0(%esp), %espsysenter_past_esp:pushl $__USER_DS /* pt_regs->ss */pushl %ebp /* pt_regs->sp (stashed in bp) */pushfl /* pt_regs->flags (except IF = 0) */orl $X86_EFLAGS_IF, (%esp) /* Fix IF */pushl $__USER_CS /* pt_regs->cs */pushl $0 /* pt_regs->ip = 0 (placeholder) */pushl %eax /* pt_regs->orig_ax */SAVE_ALL pt_regs_ax=$-ENOSYS /* save rest */testl $X86_EFLAGS_NT|X86_EFLAGS_AC|X86_EFLAGS_TF, PT_EFLAGS(%esp)jnz .Lsysenter_fix_flags.Lsysenter_flags_fixed:/** User mode is traced as though IRQs are on, and SYSENTER* turned them off.*/TRACE_IRQS_OFFmovl %esp, %eaxcall do_fast_syscall_32.../* arch/x86/kernel/asm-offsets_32.c *//* Offset from the sysenter stack to tss.sp0 */DEFINE(TSS_sysenter_sp0, offsetof(struct cpu_entry_area, tss.x86_tss.sp0) -offsetofend(struct cpu_entry_area, entry_stack_page.stack));
前文提到过，sysenter 会将 IA32_SYSENTER_ESP 加载到 esp 中，但 IA32_SYSENTER_ESP 保存的是 SYSENTER_stack 的地址，需要通过 TSS_sysenter_sp0 进行修正，指向进程的内核栈。
然后开始按照 pt_regs 的结构将相关寄存器中的值压入栈中，包括在 sysenter 前保存到 ebp 的用户态栈顶指针。由于 eip 无需保存，于是压入 0 用于占位。
最后调用 do_fast_syscall_32 ，该函数在 arch/x86/entry/common.c 中定义：
/* Returns 0 to return using IRET or 1 to return using SYSEXIT/SYSRETL. */__visible long do_fast_syscall_32(struct pt_regs *regs){/** Called using the internal vDSO SYSENTER/SYSCALL32 calling* convention. Adjust regs so it looks like we entered using int80.*/unsigned long landing_pad = (unsigned long)current->mm->context.vdso +vdso_image_32.sym_int80_landing_pad;/** SYSENTER loses EIP, and even SYSCALL32 needs us to skip forward* so that 'regs->ip -= 2' lands back on an int $0x80 instruction.* Fix it up.*/regs->ip = landing_pad;enter_from_user_mode();local_irq_enable();/* Fetch EBP from where the vDSO stashed it. */if (#ifdef CONFIG_X86_64/** Micro-optimization: the pointer we're following is explicitly* 32 bits, so it can't be out of range.*/__get_user(*(u32 *)®s->bp,(u32 __user __force *)(unsigned long)(u32)regs->sp)#elseget_user(*(u32 *)®s->bp,(u32 __user __force *)(unsigned long)(u32)regs->sp)#endif) {/* User code screwed up. */local_irq_disable();regs->ax = -EFAULT;prepare_exit_to_usermode(regs);return 0; /* Keep it simple: use IRET. */}/* Now this is just like a normal syscall. */do_syscall_32_irqs_on(regs);#ifdef CONFIG_X86_64/** Opportunistic SYSRETL: if possible, try to return using SYSRETL.* SYSRETL is available on all 64-bit CPUs, so we don't need to* bother with SYSEXIT.** Unlike 64-bit opportunistic SYSRET, we can't check that CX == IP,* because the ECX fixup above will ensure that this is essentially* never the case.*/return regs->cs == __USER32_CS && regs->ss == __USER_DS &®s->ip == landing_pad &&(regs->flags & (X86_EFLAGS_RF | X86_EFLAGS_TF)) == 0;#else/** Opportunistic SYSEXIT: if possible, try to return using SYSEXIT.** Unlike 64-bit opportunistic SYSRET, we can't check that CX == IP,* because the ECX fixup above will ensure that this is essentially* never the case.** We don't allow syscalls at all from VM86 mode, but we still* need to check VM, because we might be returning from sys_vm86.*/return static_cpu_has(X86_FEATURE_SEP) &®s->cs == __USER_CS && regs->ss == __USER_DS &®s->ip == landing_pad &&(regs->flags & (X86_EFLAGS_RF | X86_EFLAGS_TF | X86_EFLAGS_VM)) == 0;#endif}
由于没有保存 eip，我们需要计算系统调用完毕后返回到用户态的地址：current->mm->context.vdso + vdso_image_32.sym_int80_landing_pad (即跳过 sym_int80_landing_pad 来到 __kernel_vsyscall 的结尾) 覆盖掉先前压栈的 0 。
接下来就和 int 0x80 的流程一样，通过 do_syscall_32_irqs_on 从系统调用表中找到相应的处理函数进行调用。完成后，如果都符合 sysexit 的要求，返回 1，否则返回 0 。
...call do_fast_syscall_32/* XEN PV guests always use IRET path */ALTERNATIVE "testl %eax, %eax; jz .Lsyscall_32_done", \"jmp .Lsyscall_32_done", X86_FEATURE_XENPV/* Opportunistic SYSEXIT */TRACE_IRQS_ON /* User mode traces as IRQs on. */movl PT_EIP(%esp), %edx /* pt_regs->ip */movl PT_OLDESP(%esp), %ecx /* pt_regs->sp */1: mov PT_FS(%esp), %fsPTGS_TO_GSpopl %ebx /* pt_regs->bx */addl $2*4, %esp /* skip pt_regs->cx and pt_regs->dx */popl %esi /* pt_regs->si */popl %edi /* pt_regs->di */popl %ebp /* pt_regs->bp */popl %eax /* pt_regs->ax *//** Restore all flags except IF. (We restore IF separately because* STI gives a one-instruction window in which we won't be interrupted,* whereas POPF does not.)*/addl $PT_EFLAGS-PT_DS, %esp /* point esp at pt_regs->flags */btr $X86_EFLAGS_IF_BIT, (%esp)popfl/** Return back to the vDSO, which will pop ecx and edx.* Don't bother with DS and ES (they already contain __USER_DS).*/stisysexit
根据 testl %eax, %eax; jz .Lsyscall_32_done ，如果 do_fast_syscall_32 的返回值(eax)为 0 ，表示不支持快速返回，于是跳转到 Lsyscall_32_done ，通过 iret 返回。否则继续执行下面代码，将内核栈中保存的值保存到相应寄存器中，然后通过 sysexit 返回。
注意这里将原有的 eip 设置到 edx、 esp 设置到 ecx ，这是因为根据 Intel SDM，sysexit 会用 edx 来设置 eip，用 ecx 来设置 esp ，从而指向先前用户空间的代码偏移和栈偏移。并加载 SYSENTER_CS_MSR+16 到 cs，加载 SYSENTER_CS_MSR+24 到 ss 。如此一来就回到了用户态的 __kernel_vsyscall 尾端。
四、实验
我们通过 gdb 一个 C 程序来检验一下：
#include <unistd.h>#include <sys/types.h>#include <sys/stat.h>#include <fcntl.h>int main(int argc, char *argv[]){char buffer[80] = "/tmp/test";int fd = open(buffer, O_RDONLY);int size = read(fd, buffer, sizeof(buffer));close(fd);}$ gcc -m32 -g -static -o read read.c$ file readread: ELF 32-bit LSB executable, Intel 80386, version 1 (GNU/Linux), statically linked, for GNU/Linux 2.6.32, BuildID[sha1]=8a7f3d69d3e4c9582551934b0617ad78e492e48c, not stripped[txt](gdb) disas0x0804888a <+14>: push %ecx0x0804888b <+15>: sub $0x70,%esp0x0804888e <+18>: mov %ecx,%eax0x08048890 <+20>: mov 0x4(%eax),%eax0x08048893 <+23>: mov %eax,-0x6c(%ebp)0x08048896 <+26>: mov %gs:0x14,%eax0x0804889c <+32>: mov %eax,-0xc(%ebp)0x0804889f <+35>: xor %eax,%eax0x080488a1 <+37>: movl $0x706d742f,-0x5c(%ebp)0x080488a8 <+44>: movl $0x7365742f,-0x58(%ebp)0x080488af <+51>: movl $0x74,-0x54(%ebp)0x080488b6 <+58>: lea -0x50(%ebp),%edx0x080488b9 <+61>: mov $0x0,%eax0x080488be <+66>: mov $0x11,%ecx0x080488c3 <+71>: mov %edx,%edi0x080488c5 <+73>: rep stos %eax,%es:(%edi)0x080488c7 <+75>: sub $0x8,%esp0x080488ca <+78>: push $0x00x080488cc <+80>: lea -0x5c(%ebp),%eax0x080488cf <+83>: push %eax0x080488d0 <+84>: call 0x806cf30 <open>0x080488d5 <+89>: add $0x10,%esp0x080488d8 <+92>: mov %eax,-0x64(%ebp)0x080488db <+95>: sub $0x4,%esp0x080488de <+98>: push $0x500x080488e0 <+100>: lea -0x5c(%ebp),%eax0x080488e3 <+103>: push %eax0x080488e4 <+104>: pushl -0x64(%ebp)0x080488e7 <+107>: call 0x806cfa0 <read>0x080488ec <+112>: add $0x10,%esp0x080488ef <+115>: mov %eax,-0x60(%ebp)=> 0x080488f2 <+118>: sub $0xc,%esp0x080488f5 <+121>: pushl -0x64(%ebp)0x080488f8 <+124>: call 0x806d150 <close>0x080488fd <+129>: add $0x10,%esp0x08048900 <+132>: mov $0x0,%eax0x08048905 <+137>: mov -0xc(%ebp),%edx0x08048908 <+140>: xor %gs:0x14,%edx0x0804890f <+147>: je 0x8048916 <main+154>0x08048911 <+149>: call 0x806ef90 <__stack_chk_fail>0x08048916 <+154>: lea -0x8(%ebp),%esp0x08048919 <+157>: pop %ecx0x0804891a <+158>: pop %edi0x0804891b <+159>: pop %ebp0x0804891c <+160>: lea -0x4(%ecx),%esp0x0804891f <+163>: retEnd of assembler dump.
首先是 open ，将将参数 O_RDONLY (根据 #define O_RDONLY 0，值为 0x0 )，将 buffer 地址(eax) 压栈后调用系统调用 glibc 的 open 函数，disas 之：
(gdb) disas 0x806cf30Dump of assembler code for function open:0x0806cf30 <+0>: cmpl $0x0,%gs:0xc0x0806cf38 <+8>: jne 0x806cf5f0x0806cf3a <+0>: push %ebx0x0806cf3b <+1>: mov 0x10(%esp),%edx0x0806cf3f <+5>: mov 0xc(%esp),%ecx0x0806cf43 <+9>: mov 0x8(%esp),%ebx0x0806cf47 <+13>: mov $0x5,%eax0x0806cf4c <+18>: call *0x80ea9f00x0806cf52 <+24>: pop %ebx0x0806cf53 <+25>: cmp $0xfffff001,%eax0x0806cf58 <+30>: jae 0x8070590 <__syscall_error>0x0806cf5e <+36>: ret0x0806cf5f <+47>: call 0x806ea80 <__libc_enable_asynccancel>0x0806cf64 <+52>: push %eax0x0806cf65 <+53>: push %ebx0x0806cf66 <+54>: mov 0x14(%esp),%edx0x0806cf6a <+58>: mov 0x10(%esp),%ecx0x0806cf6e <+62>: mov 0xc(%esp),%ebx0x0806cf72 <+66>: mov $0x5,%eax0x0806cf77 <+71>: call *0x80ea9f00x0806cf7d <+77>: pop %ebx0x0806cf7e <+78>: xchg %eax,(%esp)0x0806cf81 <+81>: call 0x806eaf0 <__libc_disable_asynccancel>0x0806cf86 <+86>: pop %eax0x0806cf87 <+87>: cmp $0xfffff001,%eax0x0806cf8c <+92>: jae 0x8070590 <__syscall_error>0x0806cf92 <+98>: retEnd of assembler dump.
将压入栈中的参数保存到寄存器中，然后调用了 0x80ea9f0，用 x 查看该地址的值：
(gdb) x 0x80ea9f00x80ea9f0 <_dl_sysinfo>: 0xf7ffcc80
disas 之，发现来到了 __kernel_vsyscall ，并执行了sysenter指令：
(gdb) disas 0xf7ffcc80Dump of assembler code for function __kernel_vsyscall:0xf7ffcc80 <+0>: push %ecx0xf7ffcc81 <+1>: push %edx0xf7ffcc82 <+2>: push %ebp0xf7ffcc83 <+3>: mov %esp,%ebp0xf7ffcc85 <+5>: sysenter0xf7ffcc87 <+7>: int $0x800xf7ffcc89 <+9>: pop %ebp0xf7ffcc8a <+10>: pop %edx0xf7ffcc8b <+11>: pop %ecx0xf7ffcc8c <+12>: retEnd of assembler dump.
read 同理，只是有三个参数，需要 push 三次而已。
五、syscall / sysret
前文提到过，在32位下 Intel 和 AMD 对快速系统调用指令的定义有分歧，一个使用 sysenter ，另一个使用 syscall 。但到了64位下，为啥都统一成 syscall 了呢？
关于这个我在网上也没有找到权威的答案，只是一些道途听说：为什么IA-64指令集架构失败了？
在 64 位架构的开发上，Intel 和 AMD 选择了不同的道路：Intel搞出了一套全新的架构，名为安腾(IA-64)，这套架构性能完爆x86，这样用户为了更好的性能需要进行硬件换代，岂不是喜滋滋？然而这种做法在商业上取得了失败。因为 IA-64 架构虽然提高了性能，却不能向后兼容，即原来能在 x86 下跑的程序到新架构下就跑不了了，用户非常 angry 。AMD 就比较厚道，老老实实地做出了兼容 x86 的 x86_64 ，能够运行 32 位下的程序。于是农企日常翻身，逼得 Intel 反过来兼容 x86_64 架构，于是只能支持 AMD 标准中定义的 syscall 了。
这次我们直接从gdb出发，同样是之前的代码，只是这次编译成 64 位：
(gdb) disasDump of assembler code for function main:0x00000000004009ae <+0>: push %rbp0x00000000004009af <+1>: mov %rsp,%rbp0x00000000004009b2 <+4>: add $0xffffffffffffff80,%rsp0x00000000004009b6 <+8>: mov %edi,-0x74(%rbp)0x00000000004009b9 <+11>: mov %rsi,-0x80(%rbp)0x00000000004009bd <+15>: mov %fs:0x28,%rax0x00000000004009c6 <+24>: mov %rax,-0x8(%rbp)0x00000000004009ca <+28>: xor %eax,%eax0x00000000004009cc <+30>: movabs $0x7365742f706d742f,%rax0x00000000004009d6 <+40>: mov %rax,-0x60(%rbp)0x00000000004009da <+44>: movq $0x74,-0x58(%rbp)0x00000000004009e2 <+52>: lea -0x50(%rbp),%rdx0x00000000004009e6 <+56>: mov $0x0,%eax0x00000000004009eb <+61>: mov $0x8,%ecx0x00000000004009f0 <+66>: mov %rdx,%rdi0x00000000004009f3 <+69>: rep stos %rax,%es:(%rdi)0x00000000004009f6 <+72>: lea -0x60(%rbp),%rax0x00000000004009fa <+76>: mov $0x0,%esi0x00000000004009ff <+81>: mov %rax,%rdi0x0000000000400a02 <+84>: mov $0x0,%eax0x0000000000400a07 <+89>: callq 0x43e650 <open64>0x0000000000400a0c <+94>: mov %eax,-0x68(%rbp)0x0000000000400a0f <+97>: lea -0x60(%rbp),%rcx0x0000000000400a13 <+101>: mov -0x68(%rbp),%eax0x0000000000400a16 <+104>: mov $0x50,%edx0x0000000000400a1b <+109>: mov %rcx,%rsi0x0000000000400a1e <+112>: mov %eax,%edi0x0000000000400a20 <+114>: callq 0x43e6b0 <read>0x0000000000400a25 <+119>: mov %eax,-0x64(%rbp)=> 0x0000000000400a28 <+122>: mov -0x68(%rbp),%eax0x0000000000400a2b <+125>: mov %eax,%edi0x0000000000400a2d <+127>: callq 0x43e900 <close>0x0000000000400a32 <+132>: mov $0x0,%eax0x0000000000400a37 <+137>: mov -0x8(%rbp),%rdx0x0000000000400a3b <+141>: xor %fs:0x28,%rdx0x0000000000400a44 <+150>: je 0x400a4b <main+157>0x0000000000400a46 <+152>: callq 0x442010 <__stack_chk_fail>0x0000000000400a4b <+157>: leaveq0x0000000000400a4c <+158>: retqEnd of assembler dump.(gdb) disas 0x43e650Dump of assembler code for function open64:0x000000000043e650 <+0>: cmpl $0x0,0x28db65(%rip) # 0x6cc1bc <__libc_multiple_threads>0x000000000043e657 <+7>: jne 0x43e66d <open64+29>0x000000000043e659 <+0>: mov $0x2,%eax0x000000000043e65e <+5>: syscall0x000000000043e660 <+7>: cmp $0xfffffffffffff001,%rax0x000000000043e666 <+13>: jae 0x4436b0 <__syscall_error>0x000000000043e66c <+19>: retq0x000000000043e66d <+29>: sub $0x8,%rsp0x000000000043e671 <+33>: callq 0x441b70 <__libc_enable_asynccancel>0x000000000043e676 <+38>: mov %rax,(%rsp)0x000000000043e67a <+42>: mov $0x2,%eax0x000000000043e67f <+47>: syscall0x000000000043e681 <+49>: mov (%rsp),%rdi0x000000000043e685 <+53>: mov %rax,%rdx0x000000000043e688 <+56>: callq 0x441bd0 <__libc_disable_asynccancel>0x000000000043e68d <+61>: mov %rdx,%rax0x000000000043e690 <+64>: add $0x8,%rsp0x000000000043e694 <+68>: cmp $0xfffffffffffff001,%rax0x000000000043e69a <+74>: jae 0x4436b0 <__syscall_error>0x000000000043e6a0 <+80>: retqEnd of assembler dump.
open64 定义在 glibc 的 sysdeps/posix/open64.c中：
#include <fcntl.h>#include <stdarg.h>#include <sysdep-cancel.h>/* Open FILE with access OFLAG. If O_CREAT or O_TMPFILE is in OFLAG,a third argument is the file protection. */int__libc_open64 (const char *file, int oflag, ...){int mode = 0;if (__OPEN_NEEDS_MODE (oflag)){va_list arg;va_start (arg, oflag);mode = va_arg (arg, int);va_end (arg);}if (SINGLE_THREAD_P)return __libc_open (file, oflag | O_LARGEFILE, mode);int oldtype = LIBC_CANCEL_ASYNC ();int result = __libc_open (file, oflag | O_LARGEFILE, mode);LIBC_CANCEL_RESET (oldtype);return result;}weak_alias (__libc_open64, __open64)libc_hidden_weak (__open64)weak_alias (__libc_open64, open64)
再看 __libc_open ，定义在 unix/sysv/linux/generic/open.c ：
#include <errno.h>#include <fcntl.h>#include <stdarg.h>#include <stdio.h>#include <sysdep-cancel.h>/* Open FILE with access OFLAG. If O_CREAT or O_TMPFILE is in OFLAG,a third argument is the file protection. */int__libc_open (const char *file, int oflag, ...){int mode = 0;if (__OPEN_NEEDS_MODE (oflag)){va_list arg;va_start (arg, oflag);mode = va_arg (arg, int);va_end (arg);}return SYSCALL_CANCEL (openat, AT_FDCWD, file, oflag, mode);}
我们将宏展开：
SYSCALL_CANCEL(openat, AT_FDCWD, file, oflag, mode)=> __SYSCALL_CALL(openat, AT_FDCWD, file, oflag, mode)=> __SYSCALL_DISP(__SYSCALL, openat, AT_FDCWD, file, oflag, mode)=> __SYSCALL_CONCAT(__SYSCALL, 4)(openat, AT_FDCWD, file, oflag, mode)=> __SYSCALL_CONCAT_X(__SYSCALL, 4)(openat, AT_FDCWD, file, oflag, mode)=> __SYSCALL5(openat, AT_FDCWD, file, oflag, mode)=> INLINE_SYSCALL (openat, 4, AT_FDCWD, file, oflag, mode)=> INTERNAL_SYSCALL (openat, _, 4, AT_FDCWD, file, oflag, mode)=> INTERNAL_SYSCALL_NCS (__NR_openat, _, 4, AT_FDCWD, file, oflag, mode)
最终到达 INTERNAL_SYSCALL_NCS ：
# define INTERNAL_SYSCALL_NCS(name, err, nr, args...) \({ \unsigned long int resultvar; \LOAD_ARGS_##nr (args) \LOAD_REGS_##nr \asm volatile ( \"syscall\n\t" \: "=a" (resultvar) \: "0" (name) ASM_ARGS_##nr : "memory", REGISTERS_CLOBBERED_BY_SYSCALL); \(long int) resultvar; })
LOAD_ARGS_##nr 负责把参数 args 展开，然后由 LOAD_REGS_##nr 设置到相应的寄存器中，因为 syscall 通过寄存器传参。最终调用 syscall 。
根据 Intel SDM，syscall 会将当前 rip 存到 rcx ，然后将 IA32_LSTAR 加载到 rip 。同时将 IA32_STAR[47:32] 加载到cs，IA32_STAR[47:32] + 8 加载到 ss (在 GDT 中，ss 就跟在 cs 后面)。
MSR IA32_LSTAR (MSR_LSTAR) 和 IA32_STAR (MSR_STAR) 在 arch/x86/kernel/cpu/common.c 的 syscall_init 中初始化：
void syscall_init(void){wrmsr(MSR_STAR, 0, (__USER32_CS << 16) | __KERNEL_CS);wrmsrl(MSR_LSTAR, (unsigned long)entry_SYSCALL_64);#ifdef CONFIG_IA32_EMULATIONwrmsrl(MSR_CSTAR, (unsigned long)entry_SYSCALL_compat);/** This only works on Intel CPUs.* On AMD CPUs these MSRs are 32-bit, CPU truncates MSR_IA32_SYSENTER_EIP.* This does not cause SYSENTER to jump to the wrong location, because* AMD doesn't allow SYSENTER in long mode (either 32- or 64-bit).*/wrmsrl_safe(MSR_IA32_SYSENTER_CS, (u64)__KERNEL_CS);wrmsrl_safe(MSR_IA32_SYSENTER_ESP, 0ULL);wrmsrl_safe(MSR_IA32_SYSENTER_EIP, (u64)entry_SYSENTER_compat);#elsewrmsrl(MSR_CSTAR, (unsigned long)ignore_sysret);wrmsrl_safe(MSR_IA32_SYSENTER_CS, (u64)GDT_ENTRY_INVALID_SEG);wrmsrl_safe(MSR_IA32_SYSENTER_ESP, 0ULL);wrmsrl_safe(MSR_IA32_SYSENTER_EIP, 0ULL);#endif/* Flags to clear on syscall */wrmsrl(MSR_SYSCALL_MASK,X86_EFLAGS_TF|X86_EFLAGS_DF|X86_EFLAGS_IF|X86_EFLAGS_IOPL|X86_EFLAGS_AC|X86_EFLAGS_NT);}
可以看到 MSR_STAR 的第 32-47 位设置为 kernel mode 的 cs，48-63位设置为 user mode 的 cs。而 IA32_LSTAR 被设置为函数 entry_SYSCALL_64 的起始地址。
于是 syscall 时，跳转到 entry_SYSCALL_64 开始执行，其定义在 arch/x86/entry/entry_64.S：
ENTRY(entry_SYSCALL_64)/** Interrupts are off on entry.* We do not frame this tiny irq-off block with TRACE_IRQS_OFF/ON,* it is too small to ever cause noticeable irq latency.*/SWAPGS_UNSAFE_STACK// KAISER 进内核态需要切到内核页表SWITCH_KERNEL_CR3_NO_STACK/** A hypervisor implementation might want to use a label* after the swapgs, so that it can do the swapgs* for the guest and jump here on syscall.*/GLOBAL(entry_SYSCALL_64_after_swapgs)// 将用户栈偏移保存到 per-cpu 变量 rsp_scratch 中movq %rsp, PER_CPU_VAR(rsp_scratch)// 加载内核栈偏移movq PER_CPU_VAR(cpu_current_top_of_stack), %rspTRACE_IRQS_OFF/* Construct struct pt_regs on stack */pushq $__USER_DS /* pt_regs->ss */pushq PER_CPU_VAR(rsp_scratch) /* pt_regs->sp */pushq %r11 /* pt_regs->flags */pushq $__USER_CS /* pt_regs->cs */pushq %rcx /* pt_regs->ip */pushq %rax /* pt_regs->orig_ax */pushq %rdi /* pt_regs->di */pushq %rsi /* pt_regs->si */pushq %rdx /* pt_regs->dx */pushq %rcx /* pt_regs->cx */pushq $-ENOSYS /* pt_regs->ax */pushq %r8 /* pt_regs->r8 */pushq %r9 /* pt_regs->r9 */pushq %r10 /* pt_regs->r10 */pushq %r11 /* pt_regs->r11 */// 为r12-r15, rbp, rbx保留位置sub $(6*8), %rsp /* pt_regs->bp, bx, r12-15 not saved *//** If we need to do entry work or if we guess we'll need to do* exit work, go straight to the slow path.*/movq PER_CPU_VAR(current_task), %r11testl $_TIF_WORK_SYSCALL_ENTRY|_TIF_ALLWORK_MASK, TASK_TI_flags(%r11)jnz entry_SYSCALL64_slow_pathentry_SYSCALL_64_fastpath:/** Easy case: enable interrupts and issue the syscall. If the syscall* needs pt_regs, we'll call a stub that disables interrupts again* and jumps to the slow path.*/TRACE_IRQS_ONENABLE_INTERRUPTS(CLBR_NONE)#if __SYSCALL_MASK == ~0// 确保系统调用号没超过最大值，超过了则跳转到后面的符号 1 处进行返回cmpq $__NR_syscall_max, %rax#elseandl $__SYSCALL_MASK, %eaxcmpl $__NR_syscall_max, %eax#endifja 1f /* return -ENOSYS (already in pt_regs->ax) */// 除系统调用外的其他调用都通过 rcx 来传第四个参数，因此将 r10 的内容设置到 rcxmovq %r10, %rcx/** This call instruction is handled specially in stub_ptregs_64.* It might end up jumping to the slow path. If it jumps, RAX* and all argument registers are clobbered.*/// 调用系统调用表中对应的函数call *sys_call_table(, %rax, 8).Lentry_SYSCALL_64_after_fastpath_call:// 将函数返回值压到栈中，返回时弹出movq %rax, RAX(%rsp)1:/** If we get here, then we know that pt_regs is clean for SYSRET64.* If we see that no exit work is required (which we are required* to check with IRQs off), then we can go straight to SYSRET64.*/DISABLE_INTERRUPTS(CLBR_NONE)TRACE_IRQS_OFFmovq PER_CPU_VAR(current_task), %r11testl $_TIF_ALLWORK_MASK, TASK_TI_flags(%r11)jnz 1fLOCKDEP_SYS_EXITTRACE_IRQS_ON /* user mode is traced as IRQs on */movq RIP(%rsp), %rcxmovq EFLAGS(%rsp), %r11RESTORE_C_REGS_EXCEPT_RCX_R11/** This opens a window where we have a user CR3, but are* running in the kernel. This makes using the CS* register useless for telling whether or not we need to* switch CR3 in NMIs. Normal interrupts are OK because* they are off here.*/SWITCH_USER_CR3movq RSP(%rsp), %rspUSERGS_SYSRET641:/** The fast path looked good when we started, but something changed* along the way and we need to switch to the slow path. Calling* raise(3) will trigger this, for example. IRQs are off.*/TRACE_IRQS_ONENABLE_INTERRUPTS(CLBR_NONE)SAVE_EXTRA_REGSmovq %rsp, %rdicall syscall_return_slowpath /* returns with IRQs disabled */jmp return_from_SYSCALL_64entry_SYSCALL64_slow_path:/* IRQs are off. */SAVE_EXTRA_REGSmovq %rsp, %rdicall do_syscall_64 /* returns with IRQs disabled */return_from_SYSCALL_64:RESTORE_EXTRA_REGSTRACE_IRQS_IRETQ /* we're about to change IF *//** Try to use SYSRET instead of IRET if we're returning to* a completely clean 64-bit userspace context.*/movq RCX(%rsp), %rcxmovq RIP(%rsp), %r11cmpq %rcx, %r11 /* RCX == RIP */jne opportunistic_sysret_failed/** On Intel CPUs, SYSRET with non-canonical RCX/RIP will #GP* in kernel space. This essentially lets the user take over* the kernel, since userspace controls RSP.** If width of "canonical tail" ever becomes variable, this will need* to be updated to remain correct on both old and new CPUs.*/.ifne __VIRTUAL_MASK_SHIFT - 47.error "virtual address width changed -- SYSRET checks need update".endif/* Change top 16 bits to be the sign-extension of 47th bit */shl $(64 - (__VIRTUAL_MASK_SHIFT+1)), %rcxsar $(64 - (__VIRTUAL_MASK_SHIFT+1)), %rcx/* If this changed %rcx, it was not canonical */cmpq %rcx, %r11jne opportunistic_sysret_failedcmpq $__USER_CS, CS(%rsp) /* CS must match SYSRET */jne opportunistic_sysret_failedmovq R11(%rsp), %r11cmpq %r11, EFLAGS(%rsp) /* R11 == RFLAGS */jne opportunistic_sysret_failed/** SYSCALL clears RF when it saves RFLAGS in R11 and SYSRET cannot* restore RF properly. If the slowpath sets it for whatever reason, we* need to restore it correctly.** SYSRET can restore TF, but unlike IRET, restoring TF results in a* trap from userspace immediately after SYSRET. This would cause an* infinite loop whenever #DB happens with register state that satisfies* the opportunistic SYSRET conditions. For example, single-stepping* this user code:** movq $stuck_here, %rcx* pushfq* popq %r11* stuck_here:** would never get past 'stuck_here'.*/testq $(X86_EFLAGS_RF|X86_EFLAGS_TF), %r11jnz opportunistic_sysret_failed/* nothing to check for RSP */cmpq $__USER_DS, SS(%rsp) /* SS must match SYSRET */jne opportunistic_sysret_failed/** We win! This label is here just for ease of understanding* perf profiles. Nothing jumps here.*/syscall_return_via_sysret:/* rcx and r11 are already restored (see code above) */RESTORE_C_REGS_EXCEPT_RCX_R11/** This opens a window where we have a user CR3, but are* running in the kernel. This makes using the CS* register useless for telling whether or not we need to* switch CR3 in NMIs. Normal interrupts are OK because* they are off here.*/// KAISER 返回用户态需要切回用户页表SWITCH_USER_CR3/* 根据压栈的内容，恢复 rsp 为用户态的栈顶 */movq RSP(%rsp), %rspUSERGS_SYSRET64// 无法快速返回，只能退化到 iretopportunistic_sysret_failed:/** This opens a window where we have a user CR3, but are* running in the kernel. This makes using the CS* register useless for telling whether or not we need to* switch CR3 in NMIs. Normal interrupts are OK because* they are off here.*/SWITCH_USER_CR3SWAPGSjmp restore_c_regs_and_iretEND(entry_SYSCALL_64)
注意 syscall 不会保存栈指针，因此 handler 首先将当前用户态栈偏移 rsp 存到 per-cpu 变量 rsp_scratch 中，然后将 per-cpu 变量 cpu_current_top_of_stack ，即内核态的栈偏移加载到 rsp。
随后将各寄存器中的值压入内核态的栈中，包括：
rax system call number
rcx return address
r11 saved rflags (note: r11 is callee-clobbered register in C ABI)
rdi arg0
rsi arg1
rdx arg2
r10 arg3 (needs to be moved to rcx to conform to C ABI)
r8 arg4
r9 arg5
接着根据系统调用号从系统调用表(sys_call_table) 中找到相应的处理函数，如 sys_open ，进行调用。64位下系统调用定义在 arch/x86/entry/syscalls/syscall_64.tbl中，ABI 和 32 位不同。
如果一切顺利的话，最终通过 USERGS_SYSRET64 ，即 sysretq 返回。
六、总结
本文主要分析了Linux下的三种系统调用方式：int 0x80 ，sysenter 和 syscall 。
传统系统调用(int 0x80) 通过中断/异常实现，在执行 int 指令时，发生 trap。硬件找到在中断描述符表中的表项，在自动切换到内核栈 (tss.ss0 : tss.esp0) 后根据中断描述符的 segment selector 在 GDT / LDT 中找到对应的段描述符，从段描述符拿到段的基址，加载到 cs ，将 offset 加载到 eip。最后硬件将 ss / sp / eflags / cs / ip / error code 依次压到内核栈。返回时，iret 将先前压栈的 ss / sp / eflags / cs / ip 弹出，恢复用户态调用时的寄存器上下文。
sysenter 和 syscall 是为了加速系统调用所引入的新指令，通过引入新的 MSR 来存放内核态的代码和栈的段号和偏移量，从而实现快速跳转：
在调用 sysenter 时将 SYSENTER_CS_MSR 加载到 cs，将 SYSENTER_CS_MSR + 8 加载到 ss，将 IA32_SYSENTER_EIP 加载到 eip ，将 IA32_SYSENTER_ESP 加载到 esp ，整套切换到内核态。返回时，sysexit 将 IA32_SYSENTER_CS + 16 加载到 cs ，将 IA32_SYSENTER_CS + 24 加载到 cs ，而 eip 和 esp 分别从 edx 和 ecx 中加载，因此返回前应该将压栈的用户态 eip(计算出来的) 和 esp(调用前用户态保存到 ebp 进行传递) 设置到这两个寄存器中。
在调用 syscall 时，会自动将 rip 保存到 rcx ，然后将 IA32_LSTAR 加载到 rip 。同时将 IA32_STAR[47:32] 加载到 cs ，IA32_STAR[47:32] + 8 加载到 ss 。栈顶指针的切换会延迟到内核态系统调用入口点 entry_SYSCALL_64 后进行处理，将用户态栈偏移 rsp 存到 per-cpu 变量 rsp_scratch 中，然后将 per-cpu 变量 cpu_current_top_of_stack ，即内核态的栈偏移加载到 rsp。返回时，sysret 将 IA32_STAR[63:48] 加载到 cs ，IA32_STAR[63:48] + 8 加载到 ss ，而 rip 从 rcx 中加载，因此返回前应该将压栈的用户态 rip 设置到 rcx 中。对于 rsp ，返回前根据先前压栈内容先设置为用户态 rsp。
文章中肯定有遗漏或理解错误的地方，欢迎留言指正，不胜感激。
