single attention head

• import a lot

import mathimport torchimport torch.nn as nnimport torch.nn.functional as Fimport numpy as np

• causal_mask

defcausal_mask(T: int, device=None):"""Returns a bool mask where True means *masked* (disallowed).    Shape: (1, 1, T, T) suitable for broadcasting with (B, heads, T, T).    """    m = torch.triu(torch.ones((T, T), dtype=torch.bool, device=device), diagonal=1)return m.view(1, 1, T, T)

• core class

classSingleHeadSelfAttention(nn.Module):"""Single-head attention (explicit shapes)."""def__init__(self, d_model: int, d_k: int, dropout: float = 0.0, trace_shapes: bool = False):        super().__init__()        self.q = nn.Linear(d_model, d_k, bias=False)        self.k = nn.Linear(d_model, d_k, bias=False)        self.v = nn.Linear(d_model, d_k, bias=False)        self.dropout = nn.Dropout(dropout)        self.trace_shapes = trace_shapesdefforward(self, x: torch.Tensor):# x: (B, T, d_model)        B, T, _ = x.shape        q = self.q(x)  # (B,T,d_k)        k = self.k(x)  # (B,T,d_k)        v = self.v(x)  # (B,T,d_k)if self.trace_shapes:            print(f"q {q.shape}  k {k.shape}  v {v.shape}")        scale = 1.0 / math.sqrt(q.size(-1))        attn = torch.matmul(q, k.transpose(-2, -1)) * scale  # (B,T,T)        mask = causal_mask(T, device=x.device)        attn = attn.masked_fill(mask.squeeze(1), float('-inf'))        w = F.softmax(attn, dim=-1)        w = self.dropout(w)        out = torch.matmul(w, v)  # (B,T,d_k)if self.trace_shapes:            print(f"weights {w.shape}  out {out.shape}")return out, w

• 模拟输入
• 参数权重

X = np.array([[[0.1, 0.2, 0.3, 0.4],               [0.5, 0.4, 0.3, 0.2],               [0.0, 0.1, 0.0, 0.1]]], dtype=np.float32)Wq = np.array([[ 0.2, -0.1],[ 0.0,  0.1],[ 0.1,  0.2],[-0.1,  0.0]], dtype=np.float32)Wk = np.array([[ 0.1,  0.1],[ 0.0, -0.1],[ 0.2,  0.0],[ 0.0,  0.2]], dtype=np.float32)Wv = np.array([[ 0.1,  0.0],[-0.1,  0.1],[ 0.2, -0.1],[ 0.0,  0.2]], dtype=np.float32)

• 推理实施

# 模拟输入torch.manual_seed(0)x = torch.tensor(X)# 初始化 decoderattn = SingleHeadSelfAttention(d_model=4, d_k=2, trace_shapes=True)# 加载权重 [ 模型参数 ]with torch.no_grad():    attn.q.weight.copy_(torch.tensor(Wq).t())    attn.k.weight.copy_(torch.tensor(Wk).t())    attn.v.weight.copy_(torch.tensor(Wv).t())# 推理出结果out, w = attn(x)print(out.shape)print(torch.isfinite(out).all())print(torch.isfinite(w).all())

q torch.Size([1, 3, 2])  k torch.Size([1, 3, 2])  v torch.Size([1, 3, 2])weights torch.Size([1, 3, 3])  out torch.Size([1, 3, 2])torch.Size([1, 3, 2])tensor(True)tensor(True)
